Type 1 (J1772) Inlet | 32A | Single Phase

$150.00

Model

Add an additional warranty to your charger

Best Price Guarantee

QUICK OVERVIEW

Type 1 (j1772) Inlet /Receptacle/Socket 32A for Electric Vehicle Charging
The SAE J1772 inlet, an industry-standard vehicle connector for convenient charging of Plug-in Hybrid Electric Vehicles (PHEV) and Electric Vehicles Supply Equipment (EVSE). J1772 inlets and plugs support Level 1 and Level 2 charging standard of USA and Japan.

Availability: instock
EAN: N/A SKU: OC-EVSC001

Type 1 (J1772) Inlet | 32A | Single Phase

Type 1 (j1772) Inlet /Receptacle/Socket 32A for Electric Vehicle Charging
The SAE J1772 inlet, an industry-standard vehicle connector for convenient charging of Plug-in Hybrid Electric Vehicles (PHEV) and Electric Vehicles Supply Equipment (EVSE). J1772 inlets and plugs support Level 1 and Level 2 charging standard of USA and Japan.

  • Cord Length: Free end
  • Meet SAE J1772 2009 (Type 1) North American standard, UL Rated
  • Protection class IP54(in mated conditions)
  • Apply for Type 1 EV’s.

Parameters

  • 5 Pins( L,N,CP,PP,PE)
  • Rated current: 30A~32A
  • Working voltage: 120 ~240V AC
  • Insulation resistance: > 1000M Ω (DC 500V)
  • Terminal temperature rise: <50K
  • Withstand voltage: 2000V
  • Contact impedance: 0.5m Ω Max
  • Vibration resistance: Meet JDQ 53.3 requirements
  • Working temperature: -30 °C ~ + 50°C
  • CE & UL Approval

Materials

  • Shell Material: Thermo Plastic ( Insulator inflammability UL94 VO)
  • Contact bush: Copper alloy, silver plating
  • Sealing gasket: rubber or silicon rubber
  • Switch hook: Zinc Alloy

Recommended Cable  (available on order by email)

  • Cable: (TUV,UL Rated)
  • 32A: 3*6.0mm2+2*0.5mm2
  • Cord length: Free End, 3m(9.8ft), 5m(16.4ft)

Additional information

Weight 0.24 kg
phase

Single Phase

Model

CSS 2 inlet, Type 1 Inlet, Type 2 Inlet
