Item number 1107339
Packing unit 1 pc
Minimum order quantity 1 pc
Sales key XA
Product key XWBMFF
GTIN 4063151007928
Weight per piece (including packing) 12,533 g
Weight per piece (excluding packing) 11,161 g
Customs tariff number 85444290
Country of origin PL
Type of signal transmission Pulse width modulation with modulated Powerline communication in accordance with ISO/IEC 15118 / DIN SPEC 70121
Note on the connection method Crimp connection, cannot be disconnected
Coding 1500 Ω (between PE and PP)
PP signal contact Connected to cable
Temperature monitoring 2x Pt 1000
Type of charging current DC
Charging power 250 kW
Charging current 250 A
Rated voltage 1000 V DC
Type of charging current – DC Boost Mode DC Boost Mode
Charging power Up to 500 kW (Boost Mode, depending on ambient conditions. For detailed information, see the packing slip in the download area for this item.)
Charging current Up to 500 A (Boost Mode, depending on ambient conditions.)
Rated voltage 1000 V DC
Charging standard CCS Type 2
Charging mode Mode 4
Cable length 5 m
Cable type Straight, Class 6
Cable structure 2 x 70 mm² + 1 x 35 mm² + 3 x 2 x 0.75 mm²
Cable diameter 32.00 mm ± 0.4 mm
Cable outer sheath TPE-U
Bending radius Minimum 320 mm
Power contact rating 250 A at up to 40 °C
Temperature switch-off 90 °C ±1 K
Ambient temperature – operation -30 °C to +40 °C; up to +55 °C with current reduction
Degree of protection IP44 when plugged in
Insertion/withdrawal cycles >10,000
Standard IEC 62196-3
