Ocular DC Charger | 120kW | Dual Charger CCS2

Model

QUICK OVERVIEW

The Ocular Dual DC Charger is designed to supercharge electric vehicles conveniently with its robust metal casing and functional 8inch LED display.  The Ocular system is equipped to also power vehicles with high voltage battery systems. Compatible with all major EV Brands in Australia.

  • Great for the office, commercial applications or roadside
  • Charging Speed – 120 kW (800km of driving per hour of charge)
  • Can charge 2x EV’s at once
  • Compatible with all-electric vehicles with DC Capabilities
Availability: instock
EAN: N/A SKU: OC4002

Ocular DC Charger | 120kW | Dual Charger CCS2

The Ocular Dual DC Charger is designed to supercharge electric vehicles conveniently with its robust metal casing and functional 8inch LED display.  The Ocular system is equipped to also power vehicles with high voltage battery systems. The Oculars compact size and touchscreen makes it perfect for public and fleet use. Importantly unlike other units the Ocular system is designed to charge 2 vehicles simultaneously allowing you to double your vehicle servicing.

The Ocular comes standard with dual CCS 2 ports but also other configurations to order including Chademo and CCS1. The unit is compatible with all major brands in Australia.

  • Connectors: CCS2 – Option for Chademo and CCS1
  • Power: 750V – 120kW
  • Power Modules for easy servicing
  • Supply input: 260V-530V  AC
  • Supply frequency:  50-60 Hz
  • IP55
  • Warranty: 2 Years
  • Cable Length: 5m
  • Forced Air Cooling
  • Efficiency >95%
  • Power Factor: 0.99
  • Display: 8 inch Touchscreen
  • Operating Temperature: -35C to 50C
  • Network Connection: 4G and Gigabit Ethernet
  • OCPP 1.6J
  • Weight: 375 kg
  • Dimensions: 1816(H) x 1007(W) x 640(D) mm
  • Certifications: CE, TUV
  • Electrical Protection: Over current, short circuit, under voltage, ground fault, lightning surge, over temperature

Keep this in mind when installing:
For your safety, the installation must only be carried out by a licensed and qualified electrician familiar with Australian industry standards and is fully responsible for the installation

Please note charging speed is also dependent on the vehicle- The unit delivers 200Amp maximum x Voltage of the vehicle. If the vehicle can charge at a voltage above 600V it will be 120kW. If 400V it will charge at 80kW.
