Ocular Atlas Pro DC Charger | 120kW | Dual Charger CCS2

Model

Availability: instock

QUICK OVERVIEW

The Ocular Atlas Pro is built for fast, efficient charging with a sleek 21.5″ display and compact 488mm footprint, ideal for any car park. Its dual output ports allow you to charge two EVs at once, making it perfect for public spaces, offices, or commercial use. The Atlas Pro is compatible with all major EV brands in Australia, offering flexible payment options via app or tap-and-go.

Charging Speed:

60kW or 120kW options
Dual output (e.g., 60kW split into 30kW per vehicle when charging two EVs simultaneously)

Designed to handle high-voltage battery systems, the Atlas Pro ensures fast, reliable charging for all-electric vehicles with DC capabilities.

Compatible with all-electric vehicles and models including Audi, BMW, BYD, Deepal, EQC, Geely, Holden, Honda, Hyundai, Jaguar, KIA, Mazda, Mercedes Benz, Mini, MG, Mitsubishi, Nissan, Polestar, Porsche, Renault, Rivian, Tesla, Toyota, Volkswagen, Volvo, Xpeng, Zeekr, etc. If you are unsure if this charging station is right for your EV, get in touch with our team.

SKU: IOC120NY2-EE

Free Shipping Australia Wide

Up to 2 Years Warranty

Same Day Dispatch

Since 2015

The Atlas Pro is the compact, ultra-efficient DC charging solution you’ve been waiting for. With a slim 470mm profile, it’s ideal for carparks looking to offer premium charging services without sacrificing space. The 21.5” display elevates the user experience while doubling as ad space to increase your revenue potential. Perfect for highway stops or fleets of electric buses, trucks or mining vehicles. This floor mounted modular DC charging system can scale with your requirements.

This advanced charging system provides the ultimate customer experience so EV drivers can spend less time charging and get back on the road sooner. With two tethered 7m cables, this floor mounted system combines speed and function to simultaneously charge two EVs. Most EV models will be charged in under half an hour.

Available with an a credit card module add on.

Specifications:

Connectors: CCS-2 x 2, CHAdeMO (Optional)
DC Power Output: 60kW or 120kW (150V-1000V DC)
200Amp Max per Connector
Supply Input: 3-Phase 400V ± 15%
Supply frequency: 50-60 Hz
IP55
Warranty: 2 Years
Cable Length: 7m (Retractable pulley)
Forced Air Cooling
RFID & Mobile App Authentication
Credit Card Terminal as Standard
Efficiency: >=94%
Power Factor: >=0.99
Display: 21.5” CTP Touchscreen with Ad Space
Operating Temperature: -30℃ to 55℃
Network Connection: Ethernet, 4G, Modbus (TCP/IP)
OCPP Compatibility: OCPP1.6J, Upgradable to OCPP2.0.1
Weight: 300kg (60kW) / 345kg (120kW)
Dimensions: 1900(H) x 1052(W) x 470(D) mm
Certifications: CE, IEC/EN 61851-1, IEC/EN 61851-23, IEC/EN 61851-21-2, RCM
Electrical Protection: Overcurrent, Short Circuit, Over/Under Voltage, Ground Fault, Lightning Surge, Over Temperature

Keep this in mind when installing:
For your safety, the installation must only be carried out by a licensed and qualified electrician familiar with Australian industry standards and is fully responsible for the installation
