Ocular LTE Plus | w/6m Type 2 Cable | 22 kW Three Phase

Name: Ocular LTE Plus | w/6m Type 2 Cable | 22 kW Three Phase
SKU: OC20-BC-22KW-Plus
Price: 1329.00 AUD
Availability: InStock

From: $1,329.00

Model

Availability: instock

QUICK OVERVIEW

With the Ocular LTE Plus, users are sure to be charged every morning with a Smart Home EV Charging Station

Combining the beautiful and compact look of the original LTE home charging station with the new app capabilities. You can now monitor your energy use with your home charger in real time. You can review your energy trends and determine a charging schedule that aligns with off-peak periods or solar.

THREE-PHASE 22kW (up to 120km of driving range per hour of charge). For Single Phase 7kW, check the dropdown menu.
Warranty – 2 Years
Compatible with all new Type 2 EVs including Audi, BMW, BYD, EQC, Holden, Honda, Hyundai, Jaguar, KIA, Mazda, Mercedes Benz, Mini, MG, Mitsubishi, Nissan, Polestar, Porsche, Renault, Rivian, Tesla, Toyota, Volkswagen, Volvo, etc. If you are unsure if this charging station is right for your EV, get in touch with our team.

*View more information on installation

SKU: OC20-BC-22KW-Plus

The Ocular LTE Plus delivers unmatched performance and style with it’s Bluetooth APP & colourful LCD display. Users can clearly see the current charging status including charging time, voltage, current internal temperature and more

Non-hardware faults that occur during charging will be automatically fixed. Faults that require manual repair will be displayed on the LCD screen. The housing is sturdy and has an IP66 rating. It can be easily installed on the wall. If the customer prefers charger to be installed on the stand, we can provide the matching one.

Function and Accessory

Connectivity – Bluetooth to APP – EVSE Master

Input & Output

Input voltage/Output voltage – AC 230V / 400V
Adjustable output – 6A – 32A – Via Bluetooth APP
Manual override -plug and charge via the side button
3-Phase
Input frequency – 50Hz
Max. output power – 7.4KW(1 Phase) / 22kW (3-Phase)
Max. output current – 32Amp
Charging interface type – IEC 62196-2, SAE J1772

Protection

Over voltage protection
Under voltage protection
Over load protection
Short circuit protection
Earth leakage protection
Over-temp protection
Lightning protection

Function and Accessory

LCD – 3.5 inch
RCD – Type A + 6mA DC
LED Indicator light
Intelligent power adjustment

Working environment

Protection degree – IP66
Environment temperature – -40 – 75 Degrees Celsius
Relative humidity- 0-95%
Cooling – Natural Air Cooling
Standby power consumption- <8W

Mechanical

Dimension (W/H/D) – 295/195/65mm
Weight – 6 kg

Mounting Accessories

Wall-mounting bracket
Ground-mounting pole – Optional

Certificate

CE, TUV, FCC, CSA, RoHS, RCM mark

Keep this in mind when installing:

For your safety, the installation must only be carried out by a licensed and qualified electrician familiar with Australian industry standards and is fully responsible for the installation.
