The Ocular Dual AC Commercial Wallbox is a high-quality EV charging solution designed to provide reliable Mode 3 AC charging (7kW single-phase or 22kW three-phase) for electric vehicles. With OCPP 1.6J and OCPP 2.0.1 compatibility, the charger can integrate with charging management systems for remote monitoring, control, and smart charging.
Main Features:
- 7’ LCD touch display with LED charging status indicator
- 7kW (single-phase) or 22kW (three-phase) charging per port
- 230V ±20% single-phase or 400V ±20% three-phase input/output voltage
- 32A maximum current per phase per port
- Dual Type-2 socket connectors (IEC 62196-2)
- Robust powder-coated stainless steel commercial-grade housing
- Full OCPP 1.6J and OCPP 2.0.1 compatibility including smart charging profiles
- Smart load balancing compatible with Ocular Load Controller or OCPP profiles
- User authentication via RFID (ISO14443) or mobile app
- LED indicators showing charger status: charging, available, or fault
- Over current, short circuit, over voltage, under voltage, ground fault, lightning surge, and over-temperature protection
- Internal RCD protection – 30mA AC and 6mA DC leakage protection
- Dual MID certified energy meters for accurate billing and monitoring
- IP55 weather protection rating for indoor and outdoor installations
- IK10 impact protection rating
- CE and RCM compliant with IEC/EN 61851-1, IEC/EN 61851-21-2 and IEC 62196-2
- Dimensions: 550 x 320 x 177 mm
- Net weight: 18.5 kg
- Operating temperature: (-30°C to +50°C) in operation, (-40°C to +70°C) in storage
- Operating humidity: 5%–95% relative humidity (non-condensing)
- Ethernet connectivity
- Wi-Fi connectivity
- 4G module support (nano SIM optional)
- Communication protocol: Modbus TCP/IP
- Firmware management and remote trigger via OCPP
- Smart charging capability via OCPP profiles
- Local authentication list management and reservation via OCPP
- RFID access or smartphone control via OCPP platform
- Indoor and outdoor rated installation
- Wall mounted configuration
- Compatible with all Type-2 electric vehicles including Audi, BMW, BYD, Deepal, Geely, Holden, Honda, Hyundai, Jaguar, Kia, Mazda, Mercedes-Benz, Mini, MG, Mitsubishi, Nissan, Polestar, Porsche, Renault, Rivian, Tesla, Toyota, Volkswagen, Volvo, Xpeng and Zeekr. If you are unsure whether this charging station is suitable for your EV, please contact our team.
