Ocular DC Charger | 20kW | Single Charger

Model

QUICK OVERVIEW

The Ocular DC Charger 40kW. The ideal solution for affordable DC charging which is ideally suited for commercial, fleet, and large residential uses.

  • Compact Size (55 kg)
  • 40 kW single output ( 240km of additional range per hour )
  • Easy Installation
Availability: instock
EAN: N/A SKU: OC-EVD-20S

Ocular DC Charger | 20kW | Single Charger

The Ocular DC Wallbox 20kW provides DC current to directly to the vehicles batteries in EV’s which differs from AC chargers which utilise the rectifier in the vehicle to covert AC power into DC to charge the vehicle.

The Ocular DC Wallbox comes with a CCS2 Port as standard

CCS 2, Fast-charging –
AAudi, BMW, Hyundai, Jaguar, KIA, Mercedes EQ, Mini, MG, Polestar, Renault, TESLA, Volkswagen, Volvo, SEA Electric, Volvo Trucks, Daimler Trucks, Hino Truck, BYD Buses

  • CCS 2 Single charging port – Available in a dual – Please select Dual model
  • Input voltage: 320~480V AC
  • Rated input voltage: 400V AC 3-Phase
  • Frequency: 50Hz/60Hz
  • DC plug type: CCS Type 2 as standard – Chademo to order
  • Output voltage range: 150~750V DC
  • Max. output power: 20kW
  • Max. output current: 50A
  • Voltage accuracy: <±0.5%
  • Current accuracy: ≤±1% (at 20%~100% of rated power)
  • Voltage-regulating accuracy: ≤±0.5%
  • Current-regulating accuracy: ≤±1%
  • Ripple coefficient: RMS: ≤±0.5%; Peak: ≤±1%
  • Metering accuracy: 0.5%
  • Efficiency: ≥95.2%
  • Cable Length: 5m
  • RCM Certificate to Australian and European Standards

Protection

  • Over voltage protection
  • Under voltage protection
  • Over load protection
  • Leakage current protection
  • Overtemperature protection
  • Short circuit protection
  • Lightning protection

Function & Accessory

  • Indicator- Display: 4.3 inch touch screen
  • Emergency stop: Yes
  • Payment support: Yes vis OCPP
  • RFID/QR(standard)
  • Ethernet/WIFI/4G Yes

Working Environment

  • Operating temperature: -25°C ~+50°
  • Relative humidity: 5%-95% non-condensing
  • Maximum altitude: 2000m
  • Cooling: Forced air cooling
  • Standby power consumption:<25W
  • Noise emission: ≤65db
  • Protection degree: IP54

Mechanical

  • Dimension (W/H/D)- 450/630/206mm
  • Weight- 36KG

Please note charging speed is also dependent on the vehicle- The unit delivers 50Amp maximum x Voltage of the vehicle.

Additional information

Weight 55 kg
